Deskripsi ALLIED TELESIS AT-GS950/48 switch 48 port 10/100/1000TX + 4 SFP Combo

ALLIED TELESIS AT-GS950/48 WebSmart switch 48 port 10/100/1000TX 4 SFP Combo ports
https://www•alliedtelesis•com/products/switches...

GS950/48
WebSmart Gigabit Ethernet Switch

The Allied Telesis GS950/48 eco-friendly WebSmart switch upholds the Allied Telesis commitment to environmentally friendly processes and products. It is designed to minimize power consumption through the use of a high-efficiency power supply and a low power chipset.

The GS950/48 features 48 x 10/100/1000T ports and an additional four Gigabit SFP combo ports. This WebSmart switch integrates the simplicity of unmanaged switches with the performance and reliability of managed switches to provide a cost-effective solution for users to integrate management at the edge of their network. The GS950/48 provides key features using the simple web-based management function, such as port-based VLANs, IEEE 802.1p QoS, port trunking/link aggregation, port mirroring, priority queues, and IEEE 802.1x security support.

Key Features
VLAN
IEEE 802.1Q tagged - up to 255
Por t-based - up to 64
Quality of Service Classification
IEEE 802.1p tagging
Por t-based priority
Four priority queues per por t
IP Multicast Support (IPv4)
IGMP snooping (v1/v2)
Static multicast group
Spanning-Tree, IEEE 802.1d/w
IEEE 802.3ad Link Aggregation
Manual
IEEE 802.1x Port-based and MAC-based
Network Access Control
Local authentication ser ver (MD5 only)
Remote authentication through RADIUS
Dynamic VLAN assignment
RADIUS client for IEEE 802.1x
DHCP client
Statistics char ts in Web
Jumbo frames - up to 9K
Others
IEEE 802.3x flow control or HOL () blocking
Prevention ( when flow control is off)
Por t mirroring
Destination MAC filtering
Ingress/egress rate limiting
Broadcast storming control
100FX SFP suppor t
