Plastic Top Ties untuk PLN

Semi-conductive Helical-formed Top Tie for M.V.Overhead XLPE Insulated Aluminum Conductor AAAC-S 150 mm2

TECHNICAL DATA SHEET :

1. Vendor/Country of origin : SEHCO / Taiwan
2. Applicable line voltage : 20-35 kV
3. Suitable 0.0. range of insulated conductor : diameter18.57-23.37mm
4. Size of neck of pin/post insulator : "F" (diameter 73 mm)
5. Overall length : 580+/-5 mm
6. Material of tie : Rigid PVC + Black Conductive Material
7. Lay direction : Left-hand
8. Electrical tracking resistance property : Yes
9. Color code for conductor : Orange
10. Color code for insulator : Yellow
11. Standard packing : 40 pcs/carton
