JIKONG JK-B2A24S 24 String Active Battery Cell Ballancer 2A Balance Current

Battery Active Equalizer (JK-B2A24S) is a balanced solution for large-capacity series lithium battery packs Management system.The equalizer uses a supercapacitor as a medium to achieve active energy transfer equalization.

The equalizer is suitable for 2 to 24 strings of battery packs with voltage acquisition and equalization. The equalizer works for 2A The equalized current is used for energy transfer, and the equalization current does not depend on the voltage difference of the series connected cells in the battery pack. Voltage acquisition range1 V ~ 5V, accuracy ± 3mV. Applicable to all kinds of batteries on the market such as lithium iron phosphate, ternary lithium, titanic acid, lithium lead acid, etc.

The equalizer has a Bluetooth communication function and is equipped with mobile APP software. Can be viewed via Bluetooth connected equalizer Single cell voltage, view equalization status, modify setup parameters, etc. Can be applied to small sightseeing cars, scooters,Enjoy battery, battery power, base station backup power, solar power station and other products in the battery PACK, can also be used for batteries

Kelengkapan:
1 Unit Balancer B2A24S
1 Set Kabel Balancing

Balance maintenance, repair and other occasions.
2. Main technical parameters:
2.1 Main Specifications
◆ Support 2~24 strings of battery packs
◆ Real-time, active, energy transfer equalization, after the balance is reached, the pressure difference between the cells is ≤ 3mV;
◆ Single voltage range 1V ~ 5V, accuracy ± 3mV;
◆ Support all battery types such as ternary, iron lithium, lead acid, super capacitor;
◆ The equalization current is set independently in the range of 0.1~2A, independent of the cell voltage difference;
◆ Support balanced cascading to apply to more than 24 series of battery packs, in theory, can be cascaded indefinitely;
◆ Bluetooth communication function, equipped with APP, to view the state of the battery in real time;
◆ Equilibrium line resistance detection, abnormal contact failure is found in advance
