Vibration Shock Switch Sensor Module Getar Kejut Arduino Robot - SW-1801P 3P N.O

Barang, merk, kode sesuai foto

>>>>>>>>>> KY-002 Vibration Switch Module:
Detects shaking and knocking.
When the module is moved, a spring mechanism will close the circuit sending a short high signal.

Pinout:
S = Output
M = 5V
- = GND

>>>>>>>>>> SW-420 Normally Closed Alarm Vibration Sensor Module:
Applications:
- Alarms
- Smart cars
- Building, etc

Pinout:
DO = Digital Output
GND = 0V
VCC = 3.3-5V

Features:
Output = Logic 0/1 (<15mA)
PCB = 32 x 14mm
IC = LM393
Sensor = SW-420 Normally Closed

Description:
- When not vibrating:
- Vibration switch = closed conduction state
- Output = LO
- LED = ON
- When vibrating:
- Vibration switch = momentarily disconnected
- Output = HI
- LED = OFF

>>>>>>>>>> SW1801P 3P Normally Open Vibration Sensor Module:
Applications:
- Alarm
- Smart car
- Building, etc

Notes:
When a small vibration is sensed:
- The trigger time of this module will be very short
- Not enough to drive the relay

Pinout:
DO = Digital Output
GND = 0V
VCC = 3.3-5V

Features:
Output = Logic 0/1 (<15mA)
PCB = 32 x 14mm
IC = LM393
Sensor = SW-18015P Normally Open

>>>>>>>>>> SW1801P 4P Normally Open Vibration Sensor Module:
Pinout:
VCC = 3.3-5V
GND = 0V
DO = Digital Output
AO = With this shock sensor this function is invalid

Features:
Output = Logic 0/1 (<15mA)
PCB = 32 x 14mm
IC = LM393
Sensor = SW-18010P Normally Open

Description:
- When not shock:
- Vibration switch = OFF
- Output = HI
- LED = OFF
- When shock:
- Vibration switch = ON
- Output = LO
- LED = ON

>>>>>>>>>> 801S Vibration Shock Sensor Sensitivity Adjustable:
Pinout:
VCC = 3.3-5V
DO = Digital Output
GND = 0V

Features:
PCB = 15 x 45mm
IC = LM393
Sensor = 801S

Description:
- Having a signal output instruction
- With a TTL level signal, and the analog output signal
- The output valid signal is high, the light goes out
- The sensitivity is adjustable (fine-tuning)
- With mounting holes, firmware installation flexible and convenient
