MIKROTIK MTAD-5G-30D3 Parabolic dish 30dbi antenna for 5Ghz

66 orang melihat barang ini
Rp2.395.000
  • Kondisi: Baru
  • Berat: 18.500 Gram
  • Kategori: Penguat Sinyal
  • Etalase: Network Tool
Deskripsi : MikroTik mANT30 MTAD-5G-30D3

The MikroTik MTAD-5G-30-series is a carrier-class 30dBi antenna, designed to seamlessly with MikroTik Basebox for a backhaul Point to Point link. Installing the BaseBox onto the antenna requires no special tools, you simply snap it into place with the mounts provided and voila! a powerful long-range Point to Point link is at your fingertips.

This dish can be adjusted to a slanted polarization at 45deg. The instructions can be found here.

Slant Features:

Reduce RF interference in signal congested areas
Reduce the impact on local microwave devices
Unify the channel output if link deployed over a body of water

Electrical Specifications

Frequency Range: 4.7-5.875 GHz
Gain: 30dBi typically
Dual Polarization: Vertical and Horizontal
3dB Beamwidth: +/-2.5 deg
Standards: Complies with EN 302 326 DN1, DN2, DN3, DN5
VSWR: 1.4 type, 1.8 max
Port to Port Isolation: >40dB min
Front-to-Back Ratio: >30 dB
Cross Polarization: >40 dB
Power Rating: 100 watts
Impedance: 50 ohms
Elevation adjustment range: +/- 15 deg

Physical/Environmental Specifications

Reflector: Aluminum
Outdoor Rating: ETSI EN 300 019-2-4
Wind Survivability: 125mph (201kph)
Wind Load (125 mph): 400 lbs, 174 lbs with radome
Connector (2): Type RPSMA
