KINGSTON SSDNOW UV400 240GB

SSDNow UV400
Kingstons SSDNow UV400 is powered by a four-channel Marvell controller for incredible speeds and higher performance compared to a mechanical hard drive. It dramatically improves the responsiveness of your existing system and is 10 times faster than a 7200RPM hard drive1. Rugged and more reliable and durable than a hard drive, UV400 is built using Flash memory. For easy installation, UV400 is available in a bundle kit and in multiple capacities, from 120GB to 960GB2.

10 times faster than a 7200RPM hard drive1
More reliable and durable than a hard drive
Available as a bundle kit for easy installation
Multiple capacities to meet your needs

Form factor: 2.5"
Interface:
SATA Rev. 3.0 (6Gb/s) with backwards compatibility to SATA Rev. 2.0 (3Gb/s)
Capacities2: 120GB, 240GB, 480GB, 960GB
Controller: Marvell 88SS1074
NAND: TLC
Baseline Performance1:
Data Transfer (ATTO):
120GB up to 550MB/s Read and 350MB/s Write
240GB up to 550MB/s Read and 490MB/s Write
480GB up to 550MB/s Read and 500MB/s Write
960GB up to 540MB/s
Read and 500MB/s Write
Maximum Random 4k Read/Write (IOMETER):
120GB up to 90,000 IOPS and 15,000 IOPS
240GB up to 90,000 IOPS and 25,000 IOPS
480GB up to 90,000 IOPS and 35,000 IOPS
960GB up to 90,000 IOPS and 50,000 IOPS
Power Consumption:
0.672W Idle / 0.693W Avg / 0.59W (MAX) Read / 2.515W (MAX) Write
Storage temperature:
-40C~85C
Operating temperature:
0C~70C
Dimensions:
100.0mm x 69.9mm x 7.0mm
Weight: 57g
Vibration operating:
2.17G Peak (7800Hz)
Vibration non-operating:
20G Peak (102000Hz)
Life expectancy: 1 million hours MTBF
Warranty/support3:
Limited 3-year warranty with free technical support
Total Bytes Written (TBW)4:
120GB: 50TB
240GB: 100TB
480GB: 200TB
960GB: 400TB
