3DM2283 3-phase 150 - 220VAC 0.5 - 8.2A Digital Stepper Drive KN65

3DM2283 3-phase 150 - 220VAC 0.5 - 8.2A Digital Stepper Drive KN65 Descriptions The 3DM2283 is a high voltage, fully digital stepper drive developed with advanced DSP control algorithm based on the latest motion control technology. It has achieved a unique level of system smoothness, providing optimal torque and nulls mid-range instability. Its motor auto-identification and parameter auto-configuration feature offers quick setup to optimal modes with different motors. Compared with traditional analog drives, 3DM2283 can drive a stepper motor at much lower noise, lower heating, and smoother movement. Its unique features make 3DM2283 an ideal choice for high requirement applications. Feature: Anti-Resonance provides optimal torque and nulls mid-range instability Motor auto-identification and parameter auto-configuration technology, offers optimal responses with different motors Multi-Stepping allows a low resolution step input to produce a higher microstep output, thus offers smoother motor movement Microstep resolutions from full-step to25, 600. Soft-start with no “jump” when powered on Supply voltage of 80-240 VAC or 110-340 VDC Output current programmable, from 0.5A to 8.2A. It can also be set via DIP switches. Pulse input frequency up to 200 KHz TTL compatible and optically isolated input Automatic idle-current reduction (Reduction rate can be software configured) Suitable for 3-phase motors Support PUL/DIR and CW/CCW modes Over-voltage, Under-voltage, over-current, phase-error protections
