Pintu otomatis PRO Tech 1200kg Mesin Pembuka Gerbang Sliding Gate

Sliding Gate PRO Tech 1200kg Mesin pintu gerbang otomatis limit switch spring / Per bukan magnet.

PAKET 1200KG BLACK/GREY

- 1unit Motor
- 1unit Control Panel Board
- 2unit Remot Control 4chanel
- 2unit Release Key / kunci manual
- 1unit Base Plate
- 2unit Bracket Stopper
- 4pcs Dinabolt
- 4meter Gear Rack / Rel 8mm

PAKET 1200KG BLACK / GREY PAKAI HP

- 1unit Motor
- 1unit Control Panel Board
- 2unit Remot Control 4chanel
- 2unit Release Key / kunci manual
- 1unit Base Plate
- 2unit Bracket Stopper
- 4pcs Dinabolt
- 4meter Gear Rack / Rel 8mm
- 1unit chip Modul wifi colok

PAKET 1200KG BLACK / GREY PAKAI HP+SENSOR ANTI JEPIT

- 1unit Motor
- 1unit Control Panel Board
- 2unit Remot Control 4chanel
- 2unit Release Key / kunci manual
- 1unit Base Plate
- 2unit Bracket Stopper
- 4pcs Dinabolt
- 4meter Gear Rack / Rel 8mm
- 1unit chip Modul wifi colok
- 1unit Sensor Anti jepit

Spesifikasi :

Power. : AC220V  + - 10%
Motor speed : 1400rpm
Max. Gate weight. : 1200kg
Gate speed. :   12m/min
Temperature. :   - 20℃ ~ 55℃
Limit switch. :  Spring limit switch
Protecting class :   IP44

Feature

1. High sensitivity obstruction detection with automatic reverse. And the reverse force is adjustable
2. With built-in thermal protector, for protection when the motor heat up to rated temperature
3. Keypad / single button interface
4. Photo beam safety beam interface
5. Auto-close function is adjustable, and the time delay closed is adjustable.
6. Electronic Soft Start & Stop.
7. Assemble easily. In case of power failure, the gate can be opened and closed manually after releasing clutch.
