Happymodel Mobula8 DJI O3 Lite (No VTX and Camera) Micro FPV Drone - TBSCrsf

The Mobula8 is Happymodel's first attempt at an 85mm frame! This whoop comes with a Crazy F405 ELRS HD flight controller, EX1103 KV11000 motors, and Gemfan Hurricane 2023 tri-blade propellers, which have excellent power performance and extremely smooth flight characteristics. The perfect backyard ripper!

Specifications :
Camera/VTX Optio- ns: DJI O3 Compatible (No Camera or VTX), DJI O3, Walksnail Avatar HD Lite, or HDZero Nano Lite
- Item Name: Mobula8 1-2S 85mm Micro FPV whoop drone
- Size: 120mm*120mm*50mm
- Brand Name: Happymodel
- Wheelbase: 85mm
- Motor Mode: EX1103 KV11000
- Configu-ration:9N12P
- Stator Diamter:11mm
- Stator Length:3mm
- Shaft Diameter:Φ1.5mm
- Motor Dimension(Dia.*Len):Φ13.5mm*15.5mm
- Weight(g):3.8g
- No.of Cells(Lipo):1-2S

Flight Controller
MCU: STM32F405RGT6 (168MHZ, 1Mbyte FLASH)
GYRO Sensor: BMI270 (SPI connection)
Mount hole size: 25.5mm*25.5mm
Power supply: 1-2S battery input (DC 2.9V-8.7V)
Built-in 12A(each) Blheli_S 4in1 ESC
Built-in Serial ExpressLRS 2.4G
Built-in BMP280 Barometer
Built-in 8MBp blackbox
Built-in voltage meter sensor , voltage meter scale 110
Built-in current meter sensor , current meter scale 470

Onboard 4in1 ESC
Power supply: 1-2S LiPo/LiPo HV
Current: 12A continuous peak 15A (3 seconds)
Support BLHeli_S Bluejay firmware
Factory firmware: Bluejay ESC V0.19
Firmware target: Z-H-30
Default protocol: DSHOT300
When use 1s battery and high KV 0702/0802 motors, should set startup power to 1100/1200

Onboard UART ExpressLRS 2.4GHz Receiver
Packet Rate option: 25Hz/50Hz/150Hz/250Hz/500Hz
RF Frequency: 2.4GHz
Antenna: enameled copper wire 31mm length
Telemetry output Power: Default firmware version: ExpressLRS V3.0.1
Firmware target: HappyModel EP 2400 RX
Could update firmware via ExpressLRS configurator

Package Includes:
1x Happymodel Mobula8 1-2S 85mm HD Drone (Choose Camera/VTX)
1x Gemfan Hurricane 2023 Tri-blade propellers (4CW+4CCW)
1x Spare Canopy
1x Screwdriver
