GW Instek GDS-2204A 200MHz, 4-Channel, Digital Storage Oscilloscope

GW Instek GDS-2204A 200MHz, 4-Channel, Digital Storage Oscilloscope
============================================================
Features
● 200MHz Bandwidth Selection; 4 Channels
● 2GSa/s Real-time Sampling Rate and 100GSa/s Equivalent Time Sampling Rate
● 2Mega Points Record Length
● 1mV /div to 10V/div of Vertical Range
● 1ns/div to 100s/div of Time Base Range
● 80,000 wfm/s of Waveform Update Rate
============================================================
Specifications
VERTICAL SENSITIVITY
● Channels : 4ch + EXT
● Bandwidth : DC-200MHz (-3dB)
● Calculated Rise Time : 1.75ns
● Bandwidth Limit : 20M/100MHz
TRIGGER
● Source : CH1, CH2, CH3, CH4, Line, EXT, D0-D7 or D0-D15**; **Logic analyzer option only
● Trigger Mode : Auto (Supports Roll Mode for 100 ms/div and slower), Normal, Single Sequence
● Trigger Type : Edge, Pulse Width (Glitch), Video, Pulse Runt, Rise & Fall (Slope), Alternate, Glitch Trigger, Duration Trigger, Slope Trigger, Time out, Event-Delay (1-65,535 events), Time-Delay (Duration;10ns-10s), Logic*, Bus* , *with DS2-08LA or DS-16LA option
INTERFACE
● Display : 8” TFT SVGA 800 x 600 color display (LED back-light)
● USB Port : USB 2.0 Full-speed host port x 1, USB High-speed 2.0 device port x 1
● Ethernet Port (LAN) : RJ-45 connector, 10/100Mbps with HP Auto-MDIX (option)
POWER SOURCE : AC 100V - 240V, 50Hz - 60Hz, auto selection
DIMENSIONS & WEIGHT : 380(W) X 220(H) X 145(D)mm, Approx. 4.2 kg
ACCESSORIES : Quick start guide , User manual CD x 1, Power cord x 1, GTP-250A-2 :250MHz (10:1/1:1) Switchable passive probe for GDS-2202A/2204A (one per channel)

For more information please check link below :
https://www.gwinstek.com/en-global/products/downloadSeriesDownNew/1029/94
============================================================
