ASUS RT-BE92U Tri-Band WiFi 7 Smart AiMesh Extendable Router

Model

ASUS RT-BE92U


Network Standard

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
WiFi 6E (802.11ax)
WiFi 7 (802.11be)
IPv4
IPv6


Product Segment

BE9700 Ultimate BE Performance : 1032+2882+5764 Mbps


WiFi Data Rate

WiFi 7 (802.11be) (2.4GHz) : up to 1032 Mbps
WiFi 7 (802.11be) (5GHz) : up to 2882 Mbps
WiFi 7 (802.11be) (6GHz) : up to 5764 Mbps


Antenna

External Antenna x 4


Transmit / Receive

2.4GHz 3x3
5GHz 2x2
6GHz 2x2


Processor

2.0GHz Quad-Core Processor


Memory

256MB Flash and 1GB DDR4 RAM


Boosts Speed

OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming : Standard-Based and Universal
4096-QAM High Data Rate
20/40/80/160/320 MHz Bandwidth


Operating Frequency

2.4 GHz
5 GHz
6 GHz


Operating Mode

Wireless Router Mode
AiMesh Node Mode
Access Point Mode
Media Bridge Mode
Repeater Mode


I/O Ports

1 x 10Gbps for WAN/LAN
1 x 2.5Gbps for WAN/LAN
3 x 2.5 Gbps for LAN
USB 3.2 Gen1 x1


Buttons

WPS Button
Reset Button
Power Switch


LED Indicator

Power x1
WAN x1
LAN x1
2.4GHz x1
5GHz x1
6GHz x1


Power Supply

AC Input : 110V~240V(50~60Hz)
DC Output : 12V with Max. 3A Current


Package Content

RT-BE92U WiFi 7 Tri-band Router
Wall Mount Kit
RJ-45 Cable
Power Adapter
Quick Start Guide
Warranty Card


Product Dimensions

247.18 x 101.59 x 287.47 mm


AiMesh

Primary AiMesh Router
AiMesh Node


Parental Control

"Allow you to block access to unwanted websites and apps."
Web & Apps Filters
Time Scheduling
Safe Browsing
Customized Internet Schedule (Maximum Parental Control Profile : 64; Maximum Parental Control Content Cilter Rule : 64)


Guest Network

"You can create additional networks for different purposes, these networks are separate from the main network domain, to provide enhanced security, and create comprehensive network environment with customized settings." (Maximum Guest Network Rule : 2.4 GHz + 5 GHz : 3)
Guest Network Pro Encryption : Open System, WPA/WPA2/WPA3-Personal


Security

AiProtection
VPN
WPA/WPA2/WPA3 Personal
WPA/WPA2/WPA3 Enterprise
Open System & OWE
WPS
Let's Encrypt
DNS-over-TLS
SSH
Security Scan
Firewall (Maximum Firewall Keyword Filter : 64; Maximum Firewall Network Service Filter : 32; Maximum Firewall URL Filter : 64)


AiProtection

AiProtection Pro (Router Security Assessment, Malicious Site Blocking, Two-Way IPS, Infected Device Prevention and Blocking)


VPN

Instant Guard
VPN Client L2TP
VPN Client Open VPN
VPN Client PPTP
VPN Client WireGuard
VPN Server IPSec
VPN Server Open VPN
VPN Server PPTP
VPN Server WireGuard
VPN Fusion
Support Surfshark


Traffic Control

Adaptive QoS : Bandwidth Monitor, Bandwidth Limiter (Maximum Bandwidth Limiter Rule : 32)
Traditional QoS
Traffic Monitor : Real-time Traffic Monitor, Wired Traffic Monitor, Wireless Traffic Monitor
Traffic Analyzer : Traffic Analysis Period (Daily, Weekly, Monthly), Website History


WAN

Internet Connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP, IPSec
Dual WAN
3G / 4G LTE dongle
4G / 5G Auto Mobile Tethering
Port Forwarding (Maximum Port Forwarding Rule : 64)
Port Triggering (Maximum Port Triggering Rule : 32)
DMZ
DDNS
NAT Passthrough : PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Pass-Through, PPPoE Relay


LAN

DHCP Server
IGMP Snooping
IPTV
Manually Assign IP Address (Maximum Manually Assign IP Address Rule : 128)
Wake on LAN (WOL)


Wireless

MU-MIMO
UTF-8 SSID
WiFi MAC Address Filter (Maximum MAC Filters : 64)
Wireless Scheduler
Airtime Fairness
RADIUS Client
Universal Beamforming
Explicit Beamforming


USB Application

4G / 5G Auto Mobile Tethering
File System : HFS+, NTFS, vFAT, ext2, ext3, ext4
Safely Remove Disk
AiCloud
Download Master
AiDisk
Media Server
Time Machine
Samba Server
FTP Server
Shared Folder Privileges


User Interface

WEB : ASUSWRT
APP : ASUS Router APP


Administration

Configuration Backup and Restore
Diagnosis tools
Feedback System
System Log
New Device Connect Notification
Login Captcha
Connection Diagnosis
Auto Firmware Update
