CENTRIFUGAL PUMP EBARA 3SF 40-160/3.0

CENTRIFUGAL PUMP EBARA 3SF 40-160/3.0 Model Series: 3 series F version Liquid Type: Clean water and moderately aggressive fluids HP: 4 kW: 3 Max. Working Pressure: 1 MPa Temperature: Min. -10°C. Max. +90°C (Standard, E, Q1Q1EGG, Q1U3EGG, Q1AEGG, U3U3EGG, E3CEGG); Max. +110°C (H-HS-HW-HSW version). Construction - Impeller: Closed centrifugal type - Shaft Seal Type: Mechanical seal - Bearing: Sealed b all bearing Pipe Connection - Suction: Flange DN65 according DIN 2532 standard - Discharge: Flange DN40 according DIN 2532 standard
