MARTIN AUDIO LONDON V10 V 10 SPEAKER

It is capable of high output levels for its small size and its rotatable 90° x 50° HF horn provides extremely smooth coverage. Equal horizontal and vertical horn mouth dimensions ensure its excellent directivity control is maintained in both planes. The V.10’s trapezoid enclosure is constructed from 15mm engineered wood fibre and finished in a textured black paint. It is fitted with a cloth-backed protective steel grille and M8 inserts are provided for eyebolt suspension and installation.

Features
Full-range, passive two-way system
KTV specific voicing
Enhanced bass response from rear port
LF driver with demodulating ring for distortion-free vocals
User-rotatable horn
Vertical and horizontal mounting option
Cloth-backed perforated steel grille
Trapezoid enclosure with textured finish
8Ω nominal impedance
Internal crossover network with LF and HF driver protection
Twin NL4 connectors
Multiple M8 rigging inserts

Applications
Family and Premium KTV
Music bars

TYPE Compact, passive two-way system
FREQUENCY RESPONSE 65Hz-20kHz ± 3dB,
-10dB @ 49Hz
DRIVER
LF: 10” (250mm)/2.5” (63.5mm) voice coil,ferrite motor system
HF: 1” (25mm) exit/1.4” (35mm) voice coil, polyimide dome compression driver
RATED POWER 500W program, 1000W peak
SENSITIVITY 98dB
MAXIMUM SPL 125dB program, 128dB peak
NOMINAL IMPEDANCE 8Ω
DISPERSION (-6DB) 90° H x 50° V (user-rotatable)
CROSSOVER 2.8kHz passive
ENCLOSURE Trapezoid
FINISH Black textured paint
PROTECTIVE GRILLE Black perforated steel with scrim cloth backing
CONNECTORS 2 x NL4 type
PIN CONNECTIONS (INPUT) 1+/1-
PIN CONNECTIONS (LINK) 1+/- to 1+/-
FITTINGS 14 x M8 inserts
DIMENSIONS
(W) 300mm x (H) 530 x (D) 345mm
(W) 11.8ins x (H) 20.9ins x (D) 13.6ins
WEIGHT 16kg (35.3lbs)
