Kabel Single Core Tinned Copper NSGAFOU 1 x 16 Sqmm 1.8/3kv ( 16mm 2)

NSGAFOU TINNED COPPER APPLICATION Especially suitable for connections of short circuit and grounding. They are used in rail vehicles, buses, switch cabinets, continuously operating installations, pipes and pipe work duct as well as in dry interiors. ENVIRONMENT Indoor and outdoor systems. Dry, humid, wet or oli environments. SAFETY It #39;s flame retardant and self extinguishes during fire. It shouldn #39;t be burried directly underground. CONDUCTOR : Electrolytic annealed, class 2(NSGAOU) or class 5(NSGAF…) stranded plain copper wires (tinned conductor on request) SEPARATOR : A suitable tape may be applied over the conductor, with semi-conductive layer for 3,6/6 kV INSULATION : 3GI3 Type elastomer compound SEPARATOR : Appropriate material tape wrapped SCREEN : Tinned copper wires braiding for CMÖU Type SHEATH : 5GM3 Type elastomer compound COLOR : Black (other colors on request) OPERATING CHARACTERISTICS CONDUCTOR OPERATING TEMPERATURE : Max. 90ºC CONDUCTOR SHORT-CIRCUIT TEMPERATURE : Max. 250ºC WORKING TEMPERATURE : -40ºC … +80ºC (umoved) : -25ºC … +80ºC (moved) MIN BENDING RADIUS : VDE 0298-3 Tab. 3 CURRENT CARRYING CAPACITIES : VDE 0298-4 FLAME RETARDANT : VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 332-1 OIL RESISTANT : HD/EN/IEC 60811-2-1, DIN VDE 0473-811-2-1 Type : NSGAFOU Size : 1 x 16mm2 Harga untuk per Meter. Pesanan di process minimal sehari sebelum pengiriman, karena harus dipotong lebih dahulu dari Gudang Utama. * SEMUA HARGA KABEL SUDAH INCLUDE PPN 11%. * KABEL SELALU DIPERIKSA SEBELUM DIKIRIM. * KABEL YANG DIJUAL DIJAMIN ORIGINAL DAN KONDISI BARU BUKAN KABEL BEKAS. * SEMUA TRANSAKSI WAJIB ASURANSI. * JIKA PEMBELIAN ADA YANG PERLU DIKOMPLAIN, BISA VIA SYSTEM TOKOPEDIA ATAU CHAT ADMIN FTB STORE. * KAMI MENHARGAI KERJASAMA NYA UNTUK DIBICARAKAN LEBIH DAHULU SEBELUM MEMBERIKAN ULASAN AGAR TIDAK TERJADI SALAH PENGERTIAN TERIMA KASIH ATAS PERHATIAN NYA.
