DJI RS 4 Pro - Gimbal Stabilizer | 2nd-Gen Native Vertical Shooting - RS 4 Pro

Brand : DJI
Warna : Black
Tipe Aksesoris : Stabilizer

Peripheral

Accessory Port
Ronin Series Accessories (RSA)/NATO Ports
1/4""-20 Mounting Hole
‌Cold Shoe
Video Transmission/LiDAR Range Finder Port (USB-C)
RSS Camera Control Port (USB-C)
Focus Motor Port (USB-C)

Battery
Model: BG30-1950mAh-15.4V
Type: LiPo 4S
Capacity: 1950 mAh
Energy: 30 Wh
Max Runtime: 13 hours (Measured with the gimbal balanced in a level and stationary state. ‌When the gimbal is in motion, the operating time will be reduced.)
Charging Time: Approx. 1.5 hours (Measured with a charger supporting 24W fast charging. ‌It is recommended to use chargers supporting QC 2.0 or PD protocols.)
Suggested Charging Temperature: 5° to 40° C (41° to 104° F)

Connections
Bluetooth 5.1
Charging Port (USB-C)

Ronin App Requirements
iOS 11.0 or above
Android 8.0 or above

Languages Supported by the Touchscreen
English, Simplified Chinese, Traditional Chinese, German, French, Korean, Japanese, Spanish, Portuguese (Brazil), Russian, Thai


Working Performance

Tested Payload
4.5 kg

Maximum Controlled Rotation Speed
Pan: 360°/s
Tilt: 360°/s
Roll: 360°/s

Mechanical Range
Pan Axis: 360° continuous rotation
Roll Axis: -95° to +240°
Tilt Axis: -112° to +214°


Mechanical & Electrical Properties

Operating Frequency
2.40‌‌0-2.4835 GHz

Bluetooth Transmitter Power
< 8 dBm

Operating Temperature
-20° to 45° C

Weight
Gimbal: Approx. 1242 g (2.74 lbs)
Grip: Approx. 265 g (0.58 lbs)
‌Extended Grip/Tripod (Metal): Approx. 226 g (0.49 lbs)
Upper and Lower Quick-Release Plates: Approx. 110 g (0.24 lbs)

Dimensions
Folded: 271×283×75 mm (L×W×H, excluding camera, grip, and the Extended Grip/Tripod)
Unfolded: 416×223×202 mm (L×W×H, height includes grip and excludes the Extended Grip/Tripod)


DJI Ronin Image Transmitter

Connections
Power/Communication Port (USB-C)
HDMI Port (Mini HDMI)
RSS Camera Control Port (USB-C)

Expansion Port
Cold Shoe

Operating Frequency
‌‌2.40‌‌0-2.4835 GHz
5.725-5.850 GHz

Weight
126 g (0.27 lbs)

Dimensions
82×63×24 mm (L×W×H)

Transmitter Power (EIRP)
2.400-2.4835 GHz:
< 25 dBm (FCC)
< 20 dBm (CE/SRRC/MIC)

5.725-5.850 GHz:
< 25 dBm (FCC/SRRC)
< 14 dBm (CE)

Battery
Capacity: 2970 mAh
Compatible Charger: 5 V/2 A
Charging Time: Approx. 2.5 hours
Operating Time: Approx. 3.5 hours
Transmission Range
200 m (SRRC/FCC)
100 m (CE)

Latency
60 ms

Operating Current/Voltage
900 mA/3.7 V

Operating Temperature
0° to 45° C (32° to 113° F)


What's in the box RS 4 Pro
Gimbal x1
BG30 Battery Grip x1
Quick-Release Plate (Arca-Swiss/Manfrotto) x1
Extended Grip/Tripod (Metal) x1
Briefcase Handle x1
Lens-Fastening Support (Extended) x1
Multi-Camera Control Cable (USB-C, 30 cm) x1
USB-C Charging Cable (40 cm) x1
DJI Logo Sticker x1
Screw Kit x1
Carrying Case x1

What's in the box RS 4 Pro Combo
Gimbal x1
BG30 Battery Grip x1
Quick-Release Plate (Arca-Swiss/Manfrotto) x1
Extended Grip/Tripod (Metal) x1
Briefcase Handle x1
Lens-Fastening Support (Extended) x1
Multi-Camera Control Cable (USB-C, 30 cm) x2
USB-C Charging Cable (40 cm) x1
Screw Kit x1
Carrying Case x1
USB-C Power Cable (20 cm) x1
Mini-HDMI to Mini-HDMI Cable (20 cm) x1
Mini-HDMI to HDMI Cable (20 cm) x1
Mini-HDMI to Micro-HDMI Cable (20 cm) x1
Ronin Image Transmitter x1
Focus Pro Motor x1
DJI Logo Sticker x1
