BetaFPV ExpressLRS ELRS Nano TX Module - ELRS 2.4Ghz

Semua produk di etalase DOoFPV ready stock, bisa langsung dipesan. Proses kirim harian tiap Senin-Jumat jam 3 sore.
Join whatsapp group DOoFPV untuk info barang baru : https://bit.do/doofpv
============================================================

Pilih VARIAN : Versi 915Mhz atau 2.4Ghz

BETAFPV Nano RF TX module is based on the ExpressLRS project, an open-source RC link for RC applications. ExpressLRS aims to achieve the best possible link performance in both speeds, latency, and range. This makes ExpressLRS one of the fastest RC links available while still offering long-range performance.

Specification

Packet refresh rate: 25Hz/50Hz/100Hz/200Hz (915MHz/868MHz)
25Hz/50Hz/150Hz/250Hz/500Hz (2.4GHz)

RF output power: 100mW/250mW/500mW
Frequency bands (Nano RF Module 2.4G version): 2.4GHz ISM
Frequency bands (Nano RF Module 915MHz/868MHz version): 915MHz FCC/868MHz EU
Input voltage: 5V~12V
USB port: Type-C

The RF TX module output power and LED indication as shown below.
LED Color RF output power
Blue 100mW
Purple 250mW
Red 500mW

Package

1 * BETAFPV ELRS Nano TX module
1 * BETAFPV Moxon antenna
1 * Nano TX module user manual
