Air Quality Sensor Smoke Asap Dust Debu Kualitas Udara PM2.5 Particle - DSM501A

Barang, merk, kode sesuai foto GP2Y1014AU0F specifications: - Manufacturer: Sharp Microelectronics - Product Category: Air Quality Sensors - RoHS: Details - Type: Dust Sensor - Sensor Type: Dust - Operating Temperature: -10 ~ +65C - Operating Supply Voltage: 4.5 - 5.5V - Output Voltage: 0.6V - Current Rating: 11mA - Mounting Style: SMD/SMT - Packaging: Tray - Sensitivity: 0.5 V/(100 ug/m3) PMS7003 specifications: - Range of measurment: 0,3...1,0 μm 1,0...2,5 μm 2,5...10 μm - Data output: UART - Effective Range: 0...500 µg/m3 - Power Supply: 5 V - Interface Level: 3,3 V - Active Current: ≤100 mA - Standby Current: ≤200 µA - Working Temperature Range: -10 ~ +60°C - Working Humidity Range: 0...99% - MTTF: ≥3 years - Size: 48 x 37 x 12 mm SDS011 specifications: - Measurement parameters: PM2.5,PM10 - Range: 0.0-999.9μg/m3 - Rated voltage: 5V - Rated current: 70mA ±10mA - Sleep current: 4mA - Work environment： -10 ~ +50℃ - Humidity range: 70 ~ 90% - Air pressure: 86KPa ~ 110KPa - Corresponding time: 1s - Serial data output frequency: 1Hz - Minimum resolution of particle: 0.3μm - Counting yield: 70%@0.3μm, 98%@0.5μm - Relative error: Max of ±15% and ±10μg/m3 - Product size: 71x70x23mm DSM501A specifications:: - Supply voltage: DC5V±10% - Power consumption: 90mA - Operating temperature range: -10 ~ +65℃ - Operating humidity range: 95%RH or less (without dew condensation) - Recommend storage condition: -20 ~ +80℃ - Dimension: W59 * H45 * D20 (mm) - Detectable particle size: approx. 1㎛ (minimum) - Detectable range of concentration: 0 ~ 1.4㎎/㎥ - Output signal: PWM (pulse width modulation) - Time for stabilization: 1 minute after power turned on - Sensor characteristics: To be maintained in between the upper limit and lower limit of the standard dust sensor unit
