Surpass Hobby - Rocket Rc LED Program Card ESC Brushless 18A
Rp145.000
- Kondisi: Baru
- Min. Pemesanan: 1 Buah
- Etalase: PART ELEKTRONIK
LED Pogramming Card( White and Red Color) For Surpass hobby Brushless ESC
Suitable for:25A/35A/45A/60A/80A/120A ESC
Programme card Appearance description:
1:Low Voltage Cut-Off:The function is mainly to prevent the lithium battery pack
from over discharging. When using lithium battery pack, please set the suitable
value for low-voltage protection as your like.WARNING: Never use the default value
"Non-protection" for lithium battery! 3.1V,2.9V,2.7V,Non-Protection
(default value 3.1V).
2:3 start modes (Also called "Punch") from "soft"to "very aggressive" (default
value Medium)
3:Maximum brake force: (25A,45A,60A)50%,25%,75%,100%(default value 50%),
(80A,120A)25%,50%,75%,100%(default value 25%).
4:Maximum reverse force:25%,50%,75%,100%(default value 25%)
5:Neutral range: 9%(narrow),6%(Normal),12%(Wide)(default value 9%)
Programme card Method:
1. Connect BEC wires with the programmer then turn on the ESC.(80A,120A press the
keys to be not put)
2. The Green LED flashes for 2 times then LED off, that is, the connecting program card
with ESC is successful, and the Red LED on presents the current value of that item.
Otherwise, the connecting is failed.
3. Please press the Key"↓" to select different programs
4. Please press the Key"→" to select different value of the current program
5. Please press the Key "Program" to confirm above selections, the Green LED on
immediately and has gone out within 5 seconds, that is, this process is successful.
6. Please press the Key"Reset" to reset the factory setting.
Suitable for:25A/35A/45A/60A/80A/120A ESC
Programme card Appearance description:
1:Low Voltage Cut-Off:The function is mainly to prevent the lithium battery pack
from over discharging. When using lithium battery pack, please set the suitable
value for low-voltage protection as your like.WARNING: Never use the default value
"Non-protection" for lithium battery! 3.1V,2.9V,2.7V,Non-Protection
(default value 3.1V).
2:3 start modes (Also called "Punch") from "soft"to "very aggressive" (default
value Medium)
3:Maximum brake force: (25A,45A,60A)50%,25%,75%,100%(default value 50%),
(80A,120A)25%,50%,75%,100%(default value 25%).
4:Maximum reverse force:25%,50%,75%,100%(default value 25%)
5:Neutral range: 9%(narrow),6%(Normal),12%(Wide)(default value 9%)
Programme card Method:
1. Connect BEC wires with the programmer then turn on the ESC.(80A,120A press the
keys to be not put)
2. The Green LED flashes for 2 times then LED off, that is, the connecting program card
with ESC is successful, and the Red LED on presents the current value of that item.
Otherwise, the connecting is failed.
3. Please press the Key"↓" to select different programs
4. Please press the Key"→" to select different value of the current program
5. Please press the Key "Program" to confirm above selections, the Green LED on
immediately and has gone out within 5 seconds, that is, this process is successful.
6. Please press the Key"Reset" to reset the factory setting.
