HLK-PM12 AC-DC 220V to 12V Mini Power Supply Module

HLK-PM12 AC-DC 220V to 12V Mini Power Supply Module, Intelligent Household Switch Power Supply Module

HLK-PM12 PRODUCT FEATURE :
1. Meet UL, CE requirements,
2. Ultra-thin, ultra-small
2. All voltage input (AC: 90 ~ 264V)
3. Low ripple and low noise
4. Output overload and short circuit protection
5. High efficiency, high power density
6. The product is designed to meet the requirements of EMC and Safety Test
7. Low power consumption, environmental protection, no-load loss
8.100% load aging and testing

Environment Condition
Operation Temperature : -20°C~+60°C
Store Temperature : -40°C~+80°C
Relative humidity : 5%~95 %
Cooling way : Cooling by radiation
Atmospheric pressure : 80~106 Kpa
Sea level elevation : ≤2000 m
Vibration : Vibration coefficient 10~500Hz,2G10min./1cycle, 60min.each along X,Y,Z axes

Electrical Characteristic
1. Input characteristics (test at room temperature 20°C)
Rated input voltage : 100-240 VAc
Input voltage range : 90-264 VAc
Maximum input current : ≤0.2 A
Input current surge : ≤10 A
Maximum input voltage : ≤270 VAc
Enter slow start : ≤50 mS
Input Low Voltage Efficiency : Vin=110VAc Output full-load≥69 %
Input High Voltage Efficiency : Vin=220VAc output full-load≥70 %
Long-term reliability : MTBF≥100,000 h
Load rated output voltage : +12±0.1 VDc
Full rated output voltage : +12±0.2 VDc
Short-term maximum output current : ≥350 mA
The maximum output current for a long time : ≥250 mA
Voltage Regulation : ±0.2%
Load Regulation : ±0.5 %
Output ripple and noise (mVp-p) : ≤70 mV (Rated input voltage, full load. Using 20MHz of bandwidth, The load side 10uF and 0.1uF capacitor to be tested)
Switch overshoot amplitude : ≤5 %VO (Rated input voltage and output load plus 10%)
Output over-current protection : 150-150% of the output maximum load A
