GARANT Torque Analyzer 5 - 50 N·m / Torque Tester / Torsi Checker

For use of mechanical and digital brand torque wrenches (not HCT) and screwdrivers, as well as
HCT torque wrenches. Setting and testing triggering, indicating, clockwise and anti-clockwise
torque wrenches and screwdrivers.

When using the torque analyser HCT in conjunction with a torque wrench HCT:
- Simultaneous display of the measurement values of the torque wrench HCT and the torque analyser HCT on the display of the torque analyser.
- Display and automatic evaluation of the peak values achieved by the torque wrench HCT and the torque analyser HCT.
- HCT torque wrenches blocked due to overload can be released again using the torque analyser.

Advantage:
- Simple data transmission: at the push of a button the measuring result is transmitted directly to your PC application (such as Excel or Word) or to your mobile phone – no dongle necessary.
- Freedom of movement: no annoying data transmission cables.
- Independence of location: measurements can be performed directly at the machine and transmitted by radio to your application.
- Reliable data transmission: no read errors and transmission errors – multiple measuring devices can be linked together.

Supplied with:
USB-C data cable (1.8 m), power supply unit, country adapter (types A, C, G and I), calibration certificate. Supplied in a sturdy plastic case.

Merek : GARANT
P/N : 654410 50
Germany.

Technical Data:
- Maximum Torque : 50 N·m
- Direction of Tightening : For Right & Left-Hand Tightening
- Torque Measuring Accuracy : ± 1 %
- Interface : USB Interface; Bluetooth Interface
- Wireless Application : HCT Mobile App; HCT Windows App
- Test Certificate : Manufacturer’s Test Certificate
- Calibration : O4
- Resolution : 0.01 N·m
- Measuring Range : 5 N·m - 50 N·m
- Display Unit Width : 146 mm
- Display Unit Height : 86 mm
- Display Unit Depth : 161 mm
- Square Socket : 3/8 in
- Power Supply : Mains-Powered
- IP Index of Protection : IP 40
- Series : HCT
- Type of Product : Torque Analyzer.
