FESTO compact cylinder ADVU-12-40-P-A Part number: 156506

Stroke 40 mm Piston diameter 12 mm Cushioning P: Flexible cushioning rings/plates at both ends Assembly position Any Mode of operation double-acting Piston-rod end Female thread Design structure Piston Piston rod Position detection For proximity sensor Variants Single-ended piston rod Operating pressure 1.2 ... 10 bar Operating medium Compressed air in accordance with ISO8573-1:2010 [7:4:4] Note on operating and pilot medium Lubricated operation possible (subsequently required for further operation) Corrosion resistance classification CRC 2 - Moderate corrosion stress Ambient temperature -20 ... 80 °C Impact energy in end positions 0.07 J Theoretical force at 0.6 MPa (6 bar, 87 psi), retracting 51 N Theoretical force at 0.6 MPa (6 bar, 87 psi), advance 68 N Moving mass with 0 mm stroke 8 g Additional weight per 10 mm stroke 15 g Basic weight for 0 mm stroke 87 g Additional mass factor per 10 mm of stroke 2 g Mounting type with through hole with accessories Optional Pneumatic connection M5 Material of flange screw High alloy steel, non-corrosive Material cover Wrought Aluminium alloy Material of dynamic seals NBR TPE-U(PU) Material piston rod High alloy steel, non-corrosive Material cylinder barrel Wrought Aluminium alloy
