Kabel H07VVH6-F 8x1,5mm Flat PVC Power/Control cable (Merk : Delta)

Application
Use as trailing cable for cranes, conveyor plant, hoisting and lifting gear, suitable for installation in dry, moist and wet rooms.

Construction
Stranded bare copper conductor,according to IEC-60228 Class 5
PVC Insulated
Cores Identification according to HD-308, up to 5 cores colour coding, 7 cores above black colour with white numerals and green-yellow protective earth conductor
PVC outer sheath, black colour, flame retardant to IEC 60332 - 1

Electrical and Technical Data

Working voltage Ue/U : max. 450/750 V
Test voltage : 2500 VAC
Insulation resistance : 20 MΩ x Km
Minimum Bending Radius : 10 x diameter cable
Temperature Range :
-25C to + 70C (Moved)
-40C to + 70C (Unmoved)

Brand : Delta
Type : H07VVH6-F
Size : 8G1,5 / 8 x 1,5 mm

NOTE:
Kami hanya menjual barang baru dan original product .
Harga berlaku untuk per meter
Harga dan stok barang diatas dapat berubah sewaktu-waktu
Silahkan call/chat sebelum membeli..
