NSGAFOU 1x6mm single core cable 1,8/3kv (Merk:Untel) original !!

NSGAFOU APPLICATION Especially suitable for connections of short circuit and grounding. They are used in rail vehicles, buses, switch cabinets, continuously operating installations, pipes and pipe work duct as well as in dry interiors. ENVIRONMENT Indoor and outdoor systems. Dry, humid, wet or oli environments. SAFETY It #39;s flame retardant and self extinguishes during fire. It shouldn #39;t be burried directly underground. CABLE STRUCTURE * CONDUCTOR : Electrolytic annealed, class 2(NSGAOU) or class 5(NSGAF...) stranded plain copper wires ( tinned conductor on request) * SEPARATOR : A suitable tape may be applied over the conductor. with semi-conductive layer for 3.6/6KV * INSULATION : 3GI3 Type elastomer compound * SEPARATOR : Appropriate material tape wrapped * SCREEN : Tinned copper wires braiding for CMÖU type * SHEATH : 5GM3 Type elastomer compound * COLOR : Black (other colors on request) OPERATING CHARACTERISTICS CONDUCTOR OPERATING TEMPERATURE : Max. 90ºC CONDUCTOR SHORT-CIRCUIT TEMPERATURE : Max. 250ºC WORKING TEMPERATURE : -40ºC … +80ºC (umoved) : -25ºC … +80ºC (moved) MIN BENDING RADIUS : VDE 0298-3 Tab. 3 CURRENT CARRYING CAPACITIES : VDE 0298-4 FLAME RETARDANT : VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 332-1 OIL RESISTANT : HD/EN/IEC 60811-2-1, DIN VDE 0473-811-2-1 Brand : Untel Type : NSGAFOU Size : 1 x 6mm COO/Certificate Of Origin : in ready NOTE: Kami hanya menjual barang baru dan original product . Harga berlaku untuk per meter Harga dan stok barang diatas dapat berubah sewaktu-waktu Silahkan call/chat sebelum membeli. JAVA CABLE CENTER The center of your cable solution www.javacable.blogspot.com We only sell new and original items according to factory specifications Thank you for your good cooperation
