NSHTOU 12x1,5mm Rubber Insulated Crane Cables 0,6/1kv , UNTEL

APPLICATION These cables are used for crane and same machines which have heavy mechanical stresses ENVIRONMENT It is resistant to some chemicals, oil, acids and ozone. It can be used in open air, dry, damp and oily areas. SAFETY It #39;s flame retardant and self extinguishes during fire. Permitted running speed up 120m/min. Tensile stress must not exceed 15 N/mm2. Diameter of drum barrel should be min. 20 times of cable diameter. It shouldn #39;t be burried directly underground. OPERATING CHARACTERISTICS CONDUCTOR OPERATING TEMPERATURE Max. 60ºC CONDUCTOR SHORT-CIRCUIT TEMPERATURE Max. 200ºC WORKING TEMPERATURE Sabit / Fixed : -40ºC … +60ºC Hareketli /Mobile : -25ºC … +60ºC MIN BENDING RADIUS VDE 0298-3 Tab. 3 CURRENT CARRYING CAPACITIES VDE 0298-4 FLAME RETARDANT VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 60332-1 OIL RESISTANT HD/EN/IEC 60811-2-1, DIN VDE 0473-811-2-1 Brand : UNTEL Type : (N)SHTOU Size : (sesuai yang tercantum di judul etalase) CATATAN PENTING YANG HARUS DIPERHATIKAN SEBELUM ORDER Kami hanya menjual barang baru dan original product Selain size yang tercantum kami juga ready size lainnya Harga berlaku untuk per meter Harga dan Stock sewaktu-waktu dapat berubah mengikuti update harga dari factory (karena sekian banyak item admin tidak selalu update di etalase ). Silahkan call/chat sebelum membeli ya.. JAVA CABLE CENTER The center of your cable solution CONTACT MARKETING WhatsApp 085717174000 Thanks
