Splicer ai6c Signal Fire splicer Ai6 C splesing

Speksifikasi:
Fiber alignment: Core/cladding,
Motor number: 6 motor,
Splicing time: 8,
Heating mode: 18s, can be customized according to the external environment,
Fiber type: Single-mode fiber (SMF/G.652), BIF/G.657); Suitable for single mode, multi-mode, bare fiber, tail fiber, drop cable, jumper, invisible fiber fusion,
The cladding diameter: 80-150,
Splicing loss: 0.02dB（SM）、0.01dB（MM）0.04dB（DS/NZDS),
Splicing mode: Automatic focusing core alignment, conventional/high precision,
Splicing way: Automatic, semi-automatic,
Fiber holder: Three in one fixture, no need to change, suitable for single/multi-mode, multi-core cable/bare fiber, tail fiber, jumper fiber,drop cable,
Battery capacity: 5200mAh large capacity lithium battery charging time ≤3.5; It can continuously weld and heat about 160 cores,
Magnification: 300 (X or Y), 150 (X or Y),
Fiber diameter: Coating diameter: 80-150μm/Coating diameter: 100-1000μm,
Cutting length: Coating layer 250μm below: 8-16mm/coating layer 250-1000μm: 16mm,
Heat shrink tube: 60mm、50mm、40mm、25mm,
Tensile testing: standard 2N,
display: 5 inch TFT color display screen,
External lighting: USB port can be connected with EXTERNAL LED light, convenient for night construction,
Charge mobile device: The USB port can charge mobile devices such as mobile phones,
Boot time: 1s, boot can enter the working mode,
Data is stored: Unlimited, machine storage 1000 groups, the excess part can be stored in the server, can export data,
Wireless communication Based on bluetooth 4.2 protocol standard, the working band is 2.4GHz, the maximum transmission range is 60m,
Software upgrade: Mobile phone APP Internet update, enable Bluetooth synchronization upgrade machine software,
Power supply: Input AC100-240V 50/60Hz, output DC13.5V/4.8A, the current power mode can be identified, real-time monitoring of the current battery level,
Return loss: Better than 60 db.

Terima Kasih.
