Flywoo NIN 2303.5 Ultralight Fpv Drone Brushless Motor 1750KV 3000KV - 1750KV

FLYWOO NIN 2303.5 Ultralight was made to the highest standards of FPV freestyle racing. Using high grade unibell design , and the electroplating process that looks clean and aggressive at the same time. High-quality Curved N52H magnet , Japan NSK Bearing.

Great for Long range , freestyle and racing ! like 3"cinewhoop , 4"-5" toothpick , 6-7'' long range!

Specifications
KV: 1750KV

Configu-ration :12N14P
Stator Diamter : 23mm
Stator Length : 3.5mm
Shaft Diameter : 3mm(in) 1.5mm(out)
Motor Dimension(Dia.*Len) : Φ29.1*13.5mm
Weight(g) : 21.5（3cm Wire）
Idle current(10) : @10V(A) : 0.58
No.of Cells(Lipo) : 5~6S
Max Continuous Power(W) 3S : 559
Internal Resistance : 173mΩ
Max Current(3S) : 23.3A
Max.Effciency Current : (1.5-3A)>85%

KV: 3000KV

Configu-ration :12N14P
Stator Diamter : 23mm
Stator Length : 3.5mm
Shaft Diameter : 3mm(in) 1.5mm(out)
Motor Dimension(Dia.*Len) : Φ29.1*13.5mm
Weight(g) : 21.5（3cm Wire）
Idle current(10) @10V(A) : 1.25
No.of Cells(Lipo) : 3~4S
Max Continuous Power(W) 3S : 656
Internal Resistance : 71mΩ
Max Current(3S) : 41A
Max.Effciency Current : (2.5-5A)>85%

Includes
1x Flywoo Motor
