Fingerprint finger print sensor reader sidik jari FPM10A Arduino

Deskripsi:

Supply voltage: DC 3.6 ~ 6.0 V / 3.3 V
Supply current: < 120 mA
Peak current: < 140mA
Fingerprint image time: < 1.0 seconds
Window size: 14 ╳ 18 mm
Matching mode: Match mode (1 : 1)
Search mode: (1 : N)
Signature file: 256 bytes
Template files: 512 bytes
Storage capacity: max 200
Safety level: Five (from low to high: 1, 2, 3, 4, 5)
False accept rate (FAR): < 0.001% (security level 3)
False reject rate (FRR): < 1.0% (security level 3)
Search time: < 1.0 seconds (1:500, mean)
PC interface: UART (TTL logic level) or USB2.0 / USB1.1
Communication baud rate (UART): (9600 ╳ N) bps where N = 1 ~ 12 (default value N = 6, ie 57600bps)

Working environment:

Temperature: -20 ℃ - 50 ℃
Relative Humidity: 40% RH-85% RH (non-condensing)

Storage environment:

Temperature: -40 ℃ - 85 ℃
Relative humidity: < 85% H (non-condensing)

Dimensions (L ╳ W ╳ H): 56 ╳ 20 ╳ 21.5 mm
