Patch Cord Armored SC/APC to SC/APC-SM-SX-3.0-PVC~CORNING/FURUKAWA-65M - FURUKAWA-65M

Patch Cord Armored SC/APC to SC/APC-SM-SX-3.0-PVC~CORNING/FURUKAWA-65M Type G 657 A1 Applications • FTTH, LAN, Test equipment, Military industry • CATV • Measuring equipments • Fiber optic communication system • Optical active component and equipment Item information • Fiber: Simplex Singlemode 9/125 Fiber Optic Cable • Connector: SC-SC Connectors at ends • Cable Jacket: Armored/Military Tactical • OFNR (Riser) Rated • Standard Boot on each end • Color: SM Blue Connector Type SC/APC to SC/APC Fiber Type : Singlemode 9/125 Length 5m, 10m, 15m, 20m, 25m, 30m... 100m. Endface Type（nm）PC UPC APC Insertion Loss（dB）≤0.20≤0.20≤0.30 Repeatability（dB）≤0.10 Exchangeability（dB）≤0.20 Return Loss（dB）≥45≥50≥60 Core Diameter 9.2µm ± 0.4µm @1310nm Cladding Diameter 125µm ± 1µm Outer Diameter 3.2mm ± 0.10 mmMax. Attenuation 0.5dB/km @ 1310nm 0.4dB/km @ 1550nm Min Static Bend 10D Min Dynamic Bend 15D Tensile Load (long term) 200N Tensile Load (short term) 400N Crush (long term) 3000N/100mm Operation Temperature(℃)-25℃~ +70℃ Storage Temperature(℃)-40℃~ +85℃ 1. Protection from small diameter stainless steel tube, it is with higher tensile and rat bite resistance. 2. -45~85 °C working temperature, it can be used in most parts of the world. 3. More tough, not easy to be damaged during construction 4. More convenient during construction and easy for installation, it can be used in harsh environments. 5. Rugged and durable, it can reduce future maintenance costs. Features •Stainless steel tube amp; metal braid under outer LSZH jacket •Micro diameter stainless steel tube for protection •High resistance of tensile strength, pressure, rodent bite •Without damage by construction •Ensure transmission power and avoid additional attenuation •Prevent optic fiber from destroy by harsh environment,improper operation Package Include : 1 Pc Patch Cord Armored SC/APC to SC/APC

Jika Setuju pembelian artinya setujua PO +-65 HARI, jika barang nya di dalam 30 hari tidak akan segera kami kitim, tapi jika ternyata harus lebih dari 31 hari, kami akan informasikan dan pembeli setuju untuk perpanjang pesanan.
