MIC CONFERENCE BOSCH CCS900S Ultro (CCS-CM-ID) Chairman Unit

BOSCH CCS900S Ultro (CCS-CM-ID) Chairman Unit

Incorporates all functions of the CCS‑D-ID CCS Delegate Units (with the exception of the Possible To‑Speak functionality/LED)
Priority button for chairman microphone
Temporary or permanent muting of delegate microphones
Optional chime tone facility for preceding chairman announcements
Modern, unobtrusive styling to match the CCS‑D-ID CCS Delegate Units
Available with standard or extended length microphone stems

Controls and Indicators.
• Microphone on/off button
• Chairman priority button
• Rotary volume control for adjusting headphone volume
• Loudspeaker, automatically muted when microphone is on and/or headphones are connected
• Internal switch for selection of chairman announcement chime tone
• Internal switch for temporary or permanent muting of delegate microphones when chairman priority button is pressed
• Microphone has ‘on’ indicator (red LED)
• Light ring indicator on microphone stem, lights up red when microphone is on
• No Possible‑To‑Speak functionality and indicator is required because a Chairman Unit can always switch‑on the microphone, no matter the number of delegates speaking.

Interconnections:
• 1 x 2 m (78.7 in) cable terminated with a molded 7-pole circular male connector, for loop-through interconnection to delegate unit or Control Unit
• 1 x 7-pole circular female connector for loop-through interconnection to delegate units
• 2 x 3.5 mm (0.14 in) stereo headphone sockets.

Technical Specifications
Mechanical
Dimensions unit without microphone (H x W x D) : 71 x 220 x 140 mm (2.8 x 8.7 x 5.5 in)
Height with microphone in horizontal position : 134 mm (5.3 in)
Length of microphone from mounting surface : 313 mm (12.3 in)
Weight : approx. 1 kg (2.2 lb)
Mounting : tabletop (portable or fixed)
Material (top) : polymer
Material (base) : painted metal
Color (base) : charcoal (PH10736)
Color (top) : charcoal (PH10736)
