Analog Turbidity Sensor For Arduino

Analog Turbidity Sensor For Arduino berfungsi mengukur kualitas air dengan mendeteksi tingkat kekeruhannya. Sensor ini mendeteksi partikel tersuspensi dalam air dengan cara mengukur transmitansi dan hamburan cahaya yang berbanding lurus dengan kadar Total Suspended Solids (TTS). Semakin tinggi kadar TTS, maka semakin tinggi pula tingkat kekeruhan air tersebut. Sensor ini mendukung dua mode output, digital dan analog sehingga dapat dengan mudah diakses melalui Arduino atau mikrokontroler lainnya. Sensor ini dapat diaplikasikan untuk mengukur tingkat kekeruhan air pada sungai, danau, laboraturium, limbah cair, dsb. Spesifikasi: - Tegangan Kerja: 5 VDC - Arus Kerja: 40 mA (MAX) - Respon: lt;500ms - Resistansi Insulasi: 100 MOhm (Min) - Output: Digital amp; analog - Rentang Tegangan Analog: 0 - 4.5 V - Output Digital: High/Low level signal (batas atas dapat diatur dengan cara memutar potensiometer) - Temperatur Kerja: 5°C ~ 90°C ===== Analog Turbidity Sensor For Arduino is a sensor that functions to measure water quality by detecting its turbidity level. This sensor detects suspended particles in water by measuring the transmittance and scattering of light which is directly proportional to the level of Total Suspended Solids (TTS). The higher the TTS level, the higher the turbidity level of the water. This sensor supports two output modes, digital and analog so that it can be easily accessed via Arduino or other microcontrollers. This sensor can be applied to measure the turbidity level of water in rivers, lakes, laboratories, liquid waste, etc. Specification: - Working Voltage: 5 VDC - Working Current: 40 mA (MAX) - Response: lt;500ms - Insulation Resistance: 100 MOhm (Min) - Outputs: Digital amp; analogue - Analog Voltage Range: 0 - 4.5 V - Digital Output: High/Low level signal (upper limit can be set by rotating the potentiometer) - Working Temperature: 5°C ~ 90°C Datasheet : https://www.dfrobot.com/wiki/index.php/Turbidity_sensor_SKU:_SEN0189
