SET TOP BOX TV DIGITAL DVBT2 S2 COMBO Q-BOX NEW

H.264 DVB-T2 S2 Combo SPECIFICATION
Features
 MPEG2 SD/HD, MPEG4, H.264/AVC SD&HD, FULL HD (1080p),AVS/AVS+
 SCPC and MCPC receivable from C/Ku band satellite
 DVB-C/T (hybrid T/C tuner) (EN 302755/EN 300744)
 5000 channels TV and Radio programmable
 4 different favorite group’s selection
 Multi-language OSD (English, French, German, Italian, Spanish, Portuguese, Russian, Turkish,
Arabic, Polish etc)
 Fully support to 7 days Electronic Program Guide (EPG)
 True color On Screen Display
 DiSEqC 1.2 fully support, 13/18V, 0/22K, 0/12V LNB control & USALS
 Support ACM/VCM mode
 Various channel editing functions(favorite, moving, locking, renaming, deleting and sorting)
 Parental control for channels
 Support USB upgrade
 8 Timer Reservations, automatically switch to a specific channel
 Subtitle support DVB EN300743 and EBU
 Teletext support DVB ETS300472 by VBI and OSD
 Automatic save for last channel
 Channel list can be sorted by alphabetic A-Z, Scramble, Favorite, Lock, Sat
 Support FAT16/FAT32/FAT12
 List display for JPEG/BMP files
 480i/p, 576i/p, 720p, 1080i, 1080p with HDCP copy protection
 1 recording, then still can Timeshift
 MP3/JPEG File Play via USB2.0
 Built_in USB_WIFI USB_LAN 3G/4G dongle driver and Support internet.
 Support Multicas (conax,irdeto,nagra etc.)(option)
 Support youtube weather etc.
 IPTV Support (option)
 Dolby Digital support (option)
Specifications
System Resource Information
CPU/Decoder : GX6605S
Flash Memory : 8Mbyte (64Mbit)
SDRAM Memory : 1Gbit(128MB 16bit DDR3 SDARM )
DVB-S2 Tuner & Demodulator
Tuner chipset : RDA5815M
Frequency Range : 950 ∼ 2150MHz
Input Impedance : 75Ω
LNB Power and Polarization : Vertical 13VDC;Horizontal 18VDC @ 400mA (max)
22KHz±0.4KHz(0.6V±0.2V)tone, Overload Protection
Input Level Range : 65dBm ∼ -25dBm
Loop-Through : Signal loop through
DVBS Demod standard : DVB-S,DVB-S2
DVBS Demodulation : QPSK, 8PSK,16APSK,32APSK
DVBS Symbol Rate : 2 ∼ 90MSPS（Code Rate 1/2）
