Switch Automatic Door Opening | Wireless Push Button Sliding Door - PRESS
Rp645.000
Pilih warna: PRESS
Stok varian ini habis. Simpan di Wishlist untuk diingatkan ketika barang kembali tersedia.
tombol exit wireless sliding door
Adopt uniformity frequency, stability wireless signal receiving and sending
Self learning code
Frequency : 315 Mhz
Switch power supply : 6V
Receiver power supply : AC/DC 12-36 V
Maintain open time : 1-9 s adjustable
Push switch size : 203 mm x 41 mm x 12.5 mm
Receiver size : 123 mm x 50 mm x 32 mm
Keep contact time : 2s
Technical Parameter
Item Name: Automatic Door Push Button Switches
Wireless Receiver
Power supply:
Static Current: 15mA
Action Current: 80mA (DC 12V Power)
Relay contact capacity: 20A 14VDC
Wireless Transmitter
Power supply: 6V(2/pcs 3V battery)
Emission Current: 3.9mA
Life of Battery: more than 20000 times
Transmit distance: more than 25M
Operation Temperature: -42℃~45℃
Operation Humidity: 10~90%RH
Dimension: 203mm(L)×41mm（W）×12.5mm(H) (Transmitter)
123mm(L)×50mm (W) ×32mm(H) (Wireless receiver)
Adopt uniformity frequency, stability wireless signal receiving and sending
Self learning code
Frequency : 315 Mhz
Switch power supply : 6V
Receiver power supply : AC/DC 12-36 V
Maintain open time : 1-9 s adjustable
Push switch size : 203 mm x 41 mm x 12.5 mm
Receiver size : 123 mm x 50 mm x 32 mm
Keep contact time : 2s
Technical Parameter
Item Name: Automatic Door Push Button Switches
Wireless Receiver
Power supply:
Static Current: 15mA
Action Current: 80mA (DC 12V Power)
Relay contact capacity: 20A 14VDC
Wireless Transmitter
Power supply: 6V(2/pcs 3V battery)
Emission Current: 3.9mA
Life of Battery: more than 20000 times
Transmit distance: more than 25M
Operation Temperature: -42℃~45℃
Operation Humidity: 10~90%RH
Dimension: 203mm(L)×41mm（W）×12.5mm(H) (Transmitter)
123mm(L)×50mm (W) ×32mm(H) (Wireless receiver)
