Electro-Voice EVID-S44 1 Subwoofer and 4-Satellite Wall Mount Speaker

Paket
1 x Sub
4 x Speaker Satellite


Electro-Voice EVID-S44 System Features
High-performance EV-engineered 8” transducer with high-efficiency multi-mode audio crossover network.
Compact, high-density wood enclosure with port for extended bass response, secure snapon speaker grille, and quick-mount slide-on bracket system.
Easy-access signal connections with Phoenix-style connectors for quick wiring, user-friendly mode selector for stereo or mono operation, and easy-tap selector dial (supports 4/8 ohm inputs or up to 100 W / 70/100 V audio connections).
Satellite speakers feature 2” wide-range mid/high-frequency driver designed for broad, even coverage.
Satellite speakers feature multi-angle compact mounting bracket system allows for a variety of speaker angles.
Satellite speakers feature rigid high-impact ABS enclosure for durability.

Frequency Range (-10 dB)
EVID 2.1: 180 Hz - 20 kHz; EVID 40S: 180 Hz - 20 kkHz
Power Rating
200W
Connector Type
Phoenix (2-pin)
Enclosure Material
EVID 2.1: ABS (fire rated); EVID 40S: Wood (MDF);
Sensitivity 1 W/1 m
EVID 2.1: 84 dB; EVID 40S: 88dB
Height
EVID 2.1: 115mm; EVID 40S: 400mm
Width
EVID 2.1: 85mm; EVID 40S: 400mm
Depth
EVID 2.1: 95mm; EVID 40S: 230mm
Weight Net
EVID 2.1: 0.5kg; EVID 40S: 12.05kg
Shipping Weight
1 sub and 4 satellites: 18.26kg
Transformer Taps (Transformer Version Only)
EVID 2.1: NA; EVID 40S: 100 W, 50 W, 25
Impedance
EVID 2.1: 16Ω; EVID 40S: Dual 8Ω / mono 4Ω
Power Handling (Continuous / Peak)
EVID 2.1: 30 W; EVID 40S: 200W
Maximum SPL
EVID 2.1: 100 dB; EVID 40S: 114dB
Coverage, Voice
EVID 2.1: 150° x 150°; EVID 40S: Omnidirectional
Coverage, Music
EVID 2.1: 100° x 100°; EVID 40S: Omnidirectional
Transducer size
EVID 2.1: 50 mm (1.97 in); EVID 40S: 200
Bracket Adjustment Range
EVID 2.1: 160° x 60° ; EVID 40S: Fixed
Passive Power Handling
200W peak
