Kamera Ip Poe Imx415 Zoom 4K 8Mp 50X Zoom Hikvison Protokol Rtmp Ivm4200 P2P Onvif Sd 256Gb Kamera Ip

4K 8Mp 50X Zoom Imx415 Poe Ip Camera Hikvision Protocol Rtmp Ivm4200 P2P Onvif Sd 256Gb Ip Camera



4K 8Mp Ip Camera Adopts Highly Integrated Mstar338Q+Imx415 Processor, Extremely Low Power Consumption And Strong Stability; Supports H.265 Compression Algorithm To Ensure Image Quality While Effectively Reducing Network Bandwidth Occupation; Powerful Network Function, Support Standard Support Hikvision Protocol, And Compatible With Ivms-4200, Support Rtsp, Rtmp And Other Protocols, Support Alarm Picture Upload Ftp Server, Alarm Picture To E-Mail, Support Mobile Phone Remote Monitoring;
High Sensitivity, High Signal-To-Noise Cmos Image Sensor
Using The Hisilicon Mstar338Q Processing Chip+Sony Imx415 Cmos
The Highest Pixel Is Up To 8Mp, And The Highest Resolution Is Up To 8Mp (3840*2160)
H.265 Compression Algorithm, Effectively Reducing Network Bandwidth, Supporting Dual Stream, Supporting Mobile Phone Monitoring
Support Humanoid, Car, Electric Bicycle, Bicycle, Motorcycle Identification
Support Humanoid, Car, Electric Bicycle, Bicycle, Motorcycle Recognition To Trigger Sd Card Recording, Sd Card Capture, Voice Alarm, Email Alarm And Other Functions.
Support Fog Function, Support Wdr, Hdr. Support Strong Light Suppression Function.
Support Humanoid Recognition And Humanoid Alarm
Support Multiple Network Protocols: Tcp/Ip, Http, Tcp, Icmp, Udp, Arp, Igmp, Smtp, Ftp, Dhcp, Dns, Ddns, Ntp, Upnp, Rtsp, Rtmp,Etc.
Support Onvif Protocol,Hikvision Protocol
Support For Manufacturer Dynamic Domain Name And Third-Party Dynamic Domain Name Resolution
Support Alarm Picture Sending E-Mail
Support Alarm Picture Upload Ftp Server
Support Alarm Sound Outputs
Support Timing Capture Pictures To Ftp Server
Support Static Ip, Also Support Dynamic Ip (Dhcp)
Support P2P Plug And Play
Support Ie, Google, Firefox Browser
Supports Up To 6 Users To Browse At The Same Time (3 Users Per Stream)
Provide Motion Detection (Area, Sensitivity Can Be Set) Alarm Function
Support Upnp Automatic Port Mapping
Support Micro Sd Card Function, Support Up To 256Gb Micro Sd Card
Support Pc Client To Download Sd Card Video
Support Mobile Phone Download And Playback Sd Card Recording
About Rtsp:
The Rtsp Url Format For Yucheng Series Cameras Is As Follows (Assuming The Camera Ip Is 192.168.0.123):
Main Stream: Rtsp://Admin:123456@192.168.0.123/Stream0
Substream: Rtsp://Admin:123456@192.168.0.123/Stream1
For The Rtsp Url Above, If Audio Is Enabled, The Stream Will Contain Both Video And Audio.
If You Only Need Video Or Audio Data, Use The Following Url:
Main Stream Pure Video: Rtsp://Admin:123456@192.168.0.123/Video1
Substream Pure Video: Rtsp://Admin:123456@192.168.0.123/Video2
Audio Only: Rtsp://Admin:123456@192.168.0.123/Audio
Model:M-M800S-L4X-50/M-M800Sp-L4X-50(Poe)
Operating System
Embedded Linux
Main Processor
Mstar338Q
Image Sensor
Sony Imx415 1/2.8" Ultra Low Illumination Cmos Sensor
Day And Night Mode
Support
Compression Standard
Compression Standard
Video Compression Algorithm Supports H.265, H.264 High Profile, H.264 Main Profile And H.264 Baseline
Audio Compression Algorithm
G.726/G.711
Compressed Transport Stream
512Kbps-12288Bps, Can Be Customized,
Images
Maximum Image Size
8Mp (3840*2160)
Sharpness
Special Function
First Stream:4K 8Mp (3840*2160),3072*1728,2592*1944,2560*1440,2304*1296,1080P,720P
Support Fog Function, Support Wdr, Hdr. Support Strong Light Suppression Function.
Second Stream:720*480,Vga,640*360,480*360,Cif
Video Frame Rate
8Mp 20Fps,3072*1728,2592*1944,2560*1440,2304*1296,1080P,720P 30Fps
Character Overlay
Support Osd Name,Time And Date Information Overlay
Image Settings
Brightness, Contrast, Saturation, Exposure, Up And Down Reverse, Left And Right Mirroring Adjustable
Network Function
Storage Function
Supports Up To 256G Micro Sd Card Storage And Supports Scheduled Video Storage
Motion Detection
Four Independent Detection Areas Can Be Set (Sensitivity 1-100 Can Be Set)
Alarm Linkage
Alarm Sends The Picture To The Specified Mailbox; The Alarm Uploads The Picture And The Video Is Uploaded To The Ftp Server;
Network Protocol
Supports Tcp/Ip, Http, Tcp, Icmp, Udp, Arp, Igmp, Smtp, Ftp, Dhcp, Dns, Ddns, Ntp, Upnp, Rtsp,Rtmp.
Access Protocol
Supports Onvif 2.4 Protocol
Interface
Audio Input
Support External Mic
Audio Output
External Speaker
Lan Interface
Rj45 10Base-T/100Base-Tx / Poe(Ieee802.3Af/At)
Ir Night Distance
Support
Len
50X Zoom, 5X Optics And 10X Digital Zoom
Waterproof Level
Indoor
Wifi
Not Support
Working Temperature
-40 To +85 Celsius
Power
Dc12V 1A   / Poe(Ieee802.3Af/At)
Working Humidity
-10-95%
About The Protocol Spec
