YAMAHA ALL NEW R15 CONNECTED - BANGKA

Sistem Pengapian TCI
Battery GTZ4V/YTZ4V (All New R15), YTZ6V (All New R15M)
Tipe Busi MR8E9
Tipe Mesin Liquid Cooled, 4-Stroke, SOHC, 4 Valve, VVA
Jumlah/Posisi Silinder Single Cylinder
Isi Silinder (CC) 155.09 cc
Diameter x Langkah 58.0 x 58.7 mm
Perbandingan Kompresi 11.6 ± 0.4 : 1
Daya Maksimum 14.2 kW / 10000 rpm
Torsi Maksimum 14.7 Nm / 8500 rpm
Sistem Starter Elektrik Starter
Sistem Pelumasan Wet Sump
Kapasitas Oli Mesin Total =1.15L; Berkala = 0.85L; Ganti Filter Oli = 0.95L L
Sistem Bahan Bakar Fuel Injection
Tipe Kopling Multi Wet Clutch
Tipe Transmisi Manual
Pola Pengoperasian Transmisi 1-N-2-3-4-5-6

Sistem Pengapian TCI
Battery GTZ4V/YTZ4V (All New R15), YTZ6V (All New R15M)
Tipe Busi MR8E9
Tipe Mesin Liquid Cooled, 4-Stroke, SOHC, 4 Valve, VVA
Jumlah/Posisi Silinder Single Cylinder
Isi Silinder (CC) 155.09 cc
Diameter x Langkah 58.0 x 58.7 mm
Perbandingan Kompresi 11.6 ± 0.4 : 1
Daya Maksimum 14.2 kW / 10000 rpm
Torsi Maksimum 14.7 Nm / 8500 rpm
Sistem Starter Elektrik Starter
Sistem Pelumasan Wet Sump
Kapasitas Oli Mesin Total =1.15L; Berkala = 0.85L; Ganti Filter Oli = 0.95L L
Sistem Bahan Bakar Fuel Injection
Tipe Kopling Multi Wet Clutch
Tipe Transmisi Manual
Pola Pengoperasian Transmisi 1-N-2-3-4-5-6
Tipe Rangka Deltabox
Suspensi Depan Telescopic Fork (Inverted)
Suspensi Belakang Link Monoshock
Ban Depan 100/80-17M/C 52P
Ban Belakang 140/70-17M/C 66S
Rem Depan Disc Brake
Rem Belakang Disc Brake
P X L X T (Length x Width x Height) 1990 x 725 x 1135 mm
Jarak Sumbu Roda 1325 mm
Jarak Terendah Ke Tanah 170 mm
Tinggi Tempat Duduk 815 mm
Berat Isi 137 Kg (All New R15), 140 Kg (All New R15M)
Kapasitas Tangki Bensin 11 L
