MCCB 3P/3T 20A EZC100F 10kA SCHNEIDER ELECTRIC - EZC100F3020

MCCB 3P/3T 20A EZC100F 10kA SCHNEIDER ELECTRIC - EZC100F3020 #34;Schneider Electric MCCB EasyPact EZC - 20 A - 3P/3d - EZC100F3020 [Deskripsi] -Aplikasi untuk instalasi listrik dengan kapasitas pemutusan rendah. -Kapasitas Pemutusan : 7.5 kA s/d 30 kA pada 380/415 VAC. -Thermal magnetic trip unit, tidak dapat disetel (non adjustable). -Fixed type, front connection. -Satu ukuran (frame size) untuk semua rating. -Memenuhi standar IEC 60947-2. -Rated @ 125V DC (1P) dan @ 250V DC (2P in series) [Spesifikasi] 1. poles description : 3P 2. protected poles description : 3t 3. network type : -DC -AC 4. network frequency : 50/60 Hz 5. [In] rated current : 100 A at 40 °C 6. [Ui] rated insulation voltage : 690 V AC 50/60 Hz conforming to IEC 60947-2 7. [Uimp] rated impulse withstand voltage : 6 kV conforming to IEC 60947-2 8. [Ue] rated operational voltage : -550 V AC 50/60 Hz conforming to IEC 60947-2 -250 V DC conforming to IEC 60947-2 9. control type : Toggle 10. mounting mode : Fixed 11. mounting support : Backplate 12. upside connection : Front 13. downside connection : Front 14. mechanical durability : 8500 cycles 15. electrical durability : Category A : 1500 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 16. connection pitch : 25 mm 17. local signalling : Positive contact indication 18. neutral protection setting : Without protection 19. earth-leakage protection : Without 20. height : 130 mm 21. width : 75 mm 22. depth : 60 mm 23. weight: 0.78kg #34; Dijamin : * Bergaransi * 100% Produk Asli * Terpercaya UNTUK INFORMASI LEBIH LANJUT : Hubungi : 0852-7039-1034
