Serial Converter RS-232 RS-485 RS485 / RS232 to Modbus TCP/RTU Gateway

*** READY STOCK, SILAHKAN DI ORDER, USR-TCP232-306 *** *** RS485 / RS232 / RS422 to TCP IP CONVERTER GATEWAY *** This is a compact, high performance, high stability of the serial server module. It has 1 - way RS232 interface, 1 - way RS485 /RS422 interface and 1 - way Ethernet interface. Users can easily complete the interconnection between serial devices and network devices. 1. Hardware specifications NO. Model ZQWL-EthRS-D1 1 Power Supply 5VDC 2 CPU 32Bit high performance processor 3 Ethernet interface 10M/100M Adaptive Ethernet interface,2KV Electromagnetic isolation 4 RS232 baud rate support to 600~1024000, DB9 interface Isolated. baud rate support to 600~1024000, DB9 interface 5 RS485 Interface with ESD protection, the baud rate support 600~1024000,5.08mm terminal, convenient wiring Interface with ESD protection, anti-lighting. Communication isolated, baud rate support 600~460800. 5.08mm terminal, Supports Max.256 nodes 6 Indicators OnBoard RUN, RS232 and RS485/RS422 indicators 7 Reset / restore factory settings reset / restore the factory 8 Operation temperature -45~85 degrees(industrial grade) 9 Storage temperature -45~85 degrees, no condense 2. Network characteristics Support for static and dynamic IP ; IP Address/Portcan be set; TCP server Mode, each serial port supports 4 clients, multiple users can simultaneously manage one serial device ; Support DNS function ; Support network online upgrade firmware function; .Can cross segment communication Switch, router; can work in the LAN and WAN; Support ETHERNET , ARP , IP , ICMP , UDP , DHCP
