Intel Xeon E5620 | 4 Core | 2.40 GHz | 12M | 3040c023

Product Collection
Legacy Intel Xeon Processors
Code Name
Products formerly Westmere EP
Vertical Segment
Server
Processor Number
E5620
Status
Launched
Launch Date
Q1'10
Lithography
32 nm
Recommended Customer Price
$369.00 - $391.00
Use Conditions
Server/Enterprise
Performance
# of Cores
4
# of Threads
8
Processor Base Frequency
2.40 GHz
Max Turbo Frequency
2.66 GHz
Cache
12 MB SmartCache
Bus Speed
5.86 GT/s QPI
# of QPI Links
2
TDP
80 W
VID Voltage Range
0.750V-1.350V
Supplemental Information
Embedded Options Available
Yes
Datasheet
View now
Memory Specifications
Max Memory Size (dependent on memory type)
288 GB
Memory Types
DDR3 800/1066
Max # of Memory Channels
3
Max Memory Bandwidth
25.6 GB/s
Physical Address Extensions
40-bit
ECC Memory Supported ‡
Yes
Package Specifications
Sockets Supported
FCLGA1366
Max CPU Configuration
2
TCASE
77.6°C
Package Size
42.5mm X 45mm
Low Halogen Options Available
See MDDS
Advanced Technologies
Intel Turbo Boost Technology ‡
1.0
Intel Hyper-Threading Technology ‡
Yes
Intel Virtualization Technology (VT-x) ‡
Yes
Intel Virtualization Technology for Directed I/O (VT-d) ‡
Yes
Intel VT-x with Extended Page Tables (EPT) ‡
Yes
Intel 64 ‡
Yes
Instruction Set
64-bit
Instruction Set Extensions
Intel SSE4.2
Idle States
Yes
Enhanced Intel SpeedStep Technology
Yes
Intel Demand Based Switching
Yes
Thermal Monitoring Technologies
No
