Ram DDR4 Hyper X Fury RGB 16 gb - 2 x 8 gb memory longdimm PC-3200

DESCRIPTION
HyperX HX432C16FB3AK2/16 is a kit of two 1G x 64-bit (8GB)
DDR4-3200 CL16 SDRAM (Synchronous DRAM) 1Rx8, memory
module, based on eight 1G x 8-bit FBGA components per module.
Each module kit supports Intel® Extreme Memory Profiles (Intel®
XMP) 2.0. Total kit capacity is 16GB. Each module has been tested
to run at DDR4-3200 at a low latency timing of 16-18-18 at 1.35V.
The SPDs are programmed to JEDEC standard latency DDR4-2400
timing of 17-17-17 at 1.2V. Each 288-pin DIMM uses gold contact
fingers. The JEDEC standard electrical and mechanical
specifications are as follows:

SPECIFICATIONS
CL(IDD)
Row Cycle Time (tRCmin)
Refresh to Active/Refresh
Command Time (tRFCmin)
Row Active Time (tRASmin)
UL Rating
Operating Temperature
Storage Temperature
17 cycles
45.75ns(min.)
350ns(min.)
32ns(min.)
94 V - 0
0o
C to +70o
C
-40o
C to +85o
C

FEATURES
• Power Supply: VDD = 1.2V Typical
• VDDQ = 1.2V Typical
• VPP = 2.5V Typical
• VDDSPD = 2.2V to 3.6V
• On-Die termination (ODT)
• 16 internal banks; 4 groups of 4 banks each
• Bi-Directional Differential Data Strobe
• 8 bit pre-fetch
• Burst Length (BL) switch on-the-fly BL8 or BC4(Burst Chop)
• Height 1.624” (41.24mm), w/heatsink
