Anemometer Wind Speed Sensor Ukur Kecepatan Angin Arduino Raspberry Pi - RS485

Rp775.000

Pilih output: RS485

Stok varian ini habis. Simpan di Wishlist untuk diingatkan ketika barang kembali tersedia.

Kondisi: Baru
Min. Pemesanan: 1 Buah
Etalase: Smart Home Automation Part

Universal Wind Speed Sensor
(Sensor Ukur Kecepatan Angin)
Atau di Sebut Anemometer.

Datasheet:
- https://drive.google.com/file/d/1Aqghts6YKd0XL3yIt6wx-_yQxl1gNvZm/view?usp=sharing

- https://drive.google.com/file/d/18XAh6Xi9UqzB4yQ-UfQNtdbcHz_k11eu/view?usp=sharing

Konfigurasi Software:
- https://drive.google.com/file/d/1QLhXVGcQHX7XqmrpOqfOpRik6Fh9G0QT/view?usp=sharing

Deskripsi Produk
Types of Cable and outlet : Waterproof air plug type
Model : JL-FS2
Name : Universal wind sensor

Parameter
Signal output : 0-5V voltage type
Sensor Style : Three cups of formula
Start wind speed : 0. 4-0.8 m / s
Resolution : 0.1m / s
Effective wind speed measurement range : 0-30m / s or 0-60 m / s
System error : +- 3%
Transmission distance : Greater than 1000m
Transmission media : Cable transmission
Wiring : Three-wire
Operating temperature : -40 Derajat C ~ 80 Derajat C
Supply voltage : DC12-24V be common
Power : Voltage type MAX<=0.3W ; current type MAX<=0.7W
Size : See dimension on 2nd picture
Weight : 1Kg
