FRACTAL DESIGN Meshify 2 Nano | ITX form-factor enthusiasts case - Black TG Dark

Specifications :

3.5"/2.5" drive mounts
- 1 (included)

Dedicated 2.5" drive mounts
- 3 (2 included)

Expansion slots
- 2

Front interface
- 1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Audio I/O, Power button, Reset button

Total fan mounts
- 6x 120 mm or 3x 140 mm (Top 140 mm fans needs to be max 15 mm thick)

Front fan
- 2x 120/140 mm (1x Dynamic X2 GP-14 included)

Top fan
- 2x 120 or 1x 140 slim fan (max 15 mm thick)

Rear fan
- 1x 120 mm (1x Dynamic X2 GP-12 included)

Bottom fan
- 1x 120 mm (requires removal of HDD tray)

Dust filters
- Top, front and bottom

Cable routing space
- 15-25 mm

Cable routing grommets
- Yes

Fixed cable straps
- Yes

Tool-less push-to-lock
- Top, front and side panels

Captive thumbscrews
- SSD and PSU brackets

Left side panel
- Tempered glass

Right side panel
- Steel

Compatibility
Motherboard compatibility
- Mini ITX / Mini-DTX

Power supply type
- ATX

Front radiator
- 120/240, 140/280 mm (316 mm max height, 146 mm max width, 280 recommended in push configuration for easier fit)

Top radiator
- N/A

Rear radiator
- 120 mm

Bottom radiator
- N/A

PSU max length
- 165 mm recommended (200 mm without HDD-tray and modular air duct)

GPU max length
- 331 mm 306 mm with front fan

GPU max thickness
- 57 mm / 2.8 slot

CPU cooler max height
- 167 mm

Dimensions
Case dimensions (LxWxH)
- 396 x 205 x 361 mm

Case dimensions w/o feet/protrusions/screws
- 384 x 205 x 345 mm

Package dimensions (LxWxH)
- 412 x 277 x 462 mm

Other
Package contents
- Meshify 2 Nano case, User manual, Accessory box
