VGA Powercolor Radeon RX 7800 XT 16GB OC Hellhound White DDR6

SPECIFICATION
Graphics Engine RX 7800 XT 16G-L/OC/WHITE
Video Memory 16GB GDDR6
Stream Processor 3840 Units
Engine Clock(OC) up to 2213MHz(Game)¹
up to 2520MHz(Boost)²
Engine Clock(STD/Silent) up to 2124MHz(Game)¹
up to 2430MHz(Boost)²
Memory Speed 19.5 Gbps
Memory Interface 256-bit
DirectX Support 12
Bus Standard PCIE 4.0
Standard Display Connectors 1 x HDMI 2.1，3 x DisplayPort 2.1
(only 2x simultaneous DP2.1 connections can be supported)
Customized Specifications
Feature Support
OpenGL Support
AMD Stream Technology Support
AMD Eyefinity Technology Support
AMD Smart Access Memory Support
For more infromation, please refer AMD Website.
Maximum Resolution
VGA
DVI
DisplayPort 7680×4320
HDMI 7680×4320
Power Specs + Board Dimensions
Board Dimensions 322mm*134mm*50mm
332mm*147mm*50mm(with bracket)
Minimum System Power requirement (W) 750W³
Extension Power Connector Two 8-pin PCI Express Power connectors
Remark
¹Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
²Boost Clock is the maximum frequency achievable on the GPU running a burstyworkload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to:thermal conditions and variation in applications and workloads.
³Recommended power supply for AMD Radeon RX 7800 XT graphics card is minimum 750W or greater power supply with 12V output > 62A. Minimum recommended system power supply wattage is based on a PC configured with an AMD Ryzen 9 7950X processor plus typical power requirements of other system components. Your system requirements may differ.
