ASUS ROG STRIX B760-F GAMING WIFI | Intel B760 LGA 1700 DDR5 ATX

:

CPU
- Intel Socket LGA1700 for 13th Gen Intel Core Processors & 12th Gen Intel Core, Pentium Gold and Celeron Processors
- Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0

Chipset
- Intel B760 Chipset

Memory
- 4 x DIMM, Max. 128GB, DDR5 7800(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/5000/4800 MHz Non-ECC, Un-buffered Memory*
- Dual Channel Memory Architecture
- Supports Intel Extreme Memory Profile (XMP)
- OptiMem II

Graphics
- 1 x DisplayPort
- 1 x HDMI port

Expansion Slots
- Intel 13th & 12th Gen Processors*
1 x PCIe 5.0x16 slot (supports x16 mode)**
- Intel B760 Chipset**
1 x PCIe 3.0 x16 slot (supports x4 mode)***
2 x PCIe 3.0 x1 slots

Storage
- Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports*
- Intel 13th & 12th Gen Processors
- M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
- Intel B760 Chipset**
- M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 )
- M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 )
- 4 x SATA 6Gb/s ports

Ethernet
- 1 x Realtek 2.5Gb Ethernet
- TUF LANGuard

Wireless & Bluetooth
- Wi-Fi 6E
- 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
- Supports 2.4/5/6GHz frequency band*
- Bluetooth v5.3

Audio
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080
- Impedance sense for front and rear headphone outputs
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
- Supports up to 32-Bit/384 kHz playback"

Operating System
- Windows 11, Windows 10 64-bit

Form Factor
- ATX Form Factor
- 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )

:
