HOTT Hantek 6074BE 4 Channels 70Mhz Bandwidth Automotive

Hantek 6074BE 4 Channels 70Mhz Bandwidth Automotive Oscilloscope Digital USB Portrail Osciloscopio D

Semua Produk Di Toko Kami PO (Personal Pre-Order) 7-10 Hari. Harap Chat Terlebih Dahulu Sebelum Order Atau Anda Setuju Dengan Waktu Pre-Order Yang Kami Tetapkan Secara Default 15-Hari
Features:
Fit for the portable computers, table PC, and suitable for wild mobile use and business trip use. Support WIN10/ WIN8/WIN7 etc.
USB 2.0 interface plug and play, and no need extra power supply;
Great function, More than 20 kinds of automatic measurement function, PASS/FAIL Check function. Resourceful trigger function, dynamic cursor tracking, waveform record and replay function.
Good mechanical design with small size which is easy for carrying.
The outer case is made by the same material with iPad - Anodised aluminium.
It has great heat resistance and abrasive resistance with beautiful appearance.
The hardness of aluminium alloy surface is greatly improved.
4 isolated channels oscilloscope, 1GSa/s real time sampling rate, 2mV-10V/DIV high input sensitivity and large input range, 70MHz high bandwidth,
The waveform data could be output to EXCEL,BMP,JPG.
Waveform averaging, afterglow, lightness control, reverse, add, subtract, multiply, divide, X-Y display. FFT spectrum analyzer
One computer could connect with multiple oscilloscopes, expand the channel number easily.
Provide secondary development library DLL; Provide LabviewVBVCQT developing examples

Specification:

Model
Hantek6074BE
Bandwidth
70MHz
Channel
4 CH
Real-time Sampling Rate
1GSa/s
Memory Depth
64K
Time BasePrecision
±50ppm
Time Base Range
2ns/div-1000s/div (1-2-4 sequences)
Input Impedance
1MΩ 25pF
Input Sensitivity
2mV/div~10V/div
Vertical Resolution
8Bit
Vertical Displacement Range
2mV ~ 10V/div @ x1 probe; 20mV ~ 100V/div @ x10 probe;
200mV ~ 1000V/div @ x100 probe; 2V ~ 10000V/div @ x1000 probe
DC Gain Accuracy
±3%
Bandwidth
20MHz
Trigger Mode
Edge, Pulse, Video,
