Alat rekam jantung Mesin ECG/EKG 7 inci ECG301 / ECG601 3 / 6 Channel - ECG301

Electrocardiogramm Electronic ECG Heart Machine EKG Device (With Standard Accessories) Three channel electrocardiograph (with standard accessories) ECG 3030p Digital 3/6-Channel ECG Features:  7 inch high resolution color touch-screen  12-lead simultaneous acquisition and display  Auto analysis and diagnosis for routine ECG parameters  Support USB flash disk and micro SD card to extend memory  Software upgrade automatically via USB/SD card. Specifications: 1. Lead: Standard 12 leads; 2. Input circuit: Floating; Built-in defibrillator protection 3. Acquisition Mode: Simultaneous 12 leads acquisition; 4. Measurement Range: ±5mVpp; 5. Time Constant≥3.2s; 6. Frequency Response: 0.05Hz~150Hz (-3dB); 7. Sensitivity: 2.5mm/mV, 5 mm/mV, 10 mm/mV, 20 mm/mV; 8. Input Impedance ≥50MΩ; 9. Input Circuit Current＜0.05µA; 10. Noise Level ＜15µVp-p; 11. Anti-baseline Drift: Automatic; 12. Patient Current Leakage＜10µA (220V-240V); 13. Filter: EMG Filter: 25 Hz / 30 Hz / 40Hz/75 Hz / 100 Hz / 150Hz DFT Filter: 0.05 Hz/ 0.15 Hz AC Filter: 50 Hz / 60Hz 14. CMRR: 100dB; 15. Recording Mode: Automatic: 3CH×4+1R, 3CH×4，3CHx2+2CHx3,3CHx2+2CHx3+1R,6CHX2 Manual: 3CH, 2CH, 3CH+1R, 2CH+1R Rhythm: Any lead selectable 16. Recording way: Thermal printing system; 17. Recording Paper: Roll 80mmx20M; 18. Paper Speed: 12.5 mm/s, 25 mm/s, 50 mm/s; 19. Safety Standard: IEC I/CF; 20. Sample Rate: Normal: 1000sps/channel 21. Power Supply: AC: 100~240V, 50/60Hz, 30VA~100VA DC: 14.8V/2200mAh, built-in lithium battery
